Thermostatic Diverter

Experience the epitome of luxury and functionality with Amari’s AL-55-MB Thermostatic Diverter Select. Engineered to provide 4-outlet versatility with integrated volume control,

 this innovative fixture redefines the standard for precision temperature management and showering convenience. Explore a range of thermostatic diverter solutions that blend Italian-inspired aesthetics with high-performance engineering.

AL-55-MB: Elevating Your Shower Experience

Are you tired of fluctuating water temperatures disrupting your relaxation? Say goodbye to inconsistent thermal surges and hello to pure indulgence with the Amari thermostatic diverter. Our cutting-edge Select technology enables effortless control over multiple outlets, delivering a customized, safe, and sophisticated shower environment tailored to your lifestyle.

FEATURES

MAX Performance

 High Flow Efficiency: The AL-55-MB thermostatic diverter works efficiently even in low-pressure conditions, ensuring a powerful spray from all 4 outlets.

 No Pressure Pump Required: Specifically designed to maintain high-volume water delivery without the need for additional boosting equipment.

Volume Control Select: Integrated volume control allows you to fine-tune the water flow for a truly bespoke experience.

MAX Flexibility

4-Outlet Versatility: Manage overhead showers, hand showers, body jets, and spouts simultaneously or independently through a single thermostatic diverter.

PVD Finish Collection: Available in an industry-leading range of 10 premium finishes, including Brushed Brass, Matt Black, Rose Gold, French Gold, and Brushed Gun Metal.

Universal Concealed Body: Housed in a sleek contemporary design, the concealed body allows for easy installation and a minimalistic wall profile.

MAX Safety

· Thermostat Precision: Set your desired temperature effortlessly; the thermostatic diverter maintains it with unerring accuracy despite pressure changes elsewhere in the home.

Child Lock Safety: Includes a safety stop at 38°C to prevent accidental rotation to dangerous temperatures, protecting children and the elderly.

Anti-Scald Technology: The system automatically shuts off the hot water supply instantly if the cold water supply fails.

Mechanical Reliability: Built with a high-performance non-electrical cartridge for lifelong durability.

How to Fit the Amari Thermostatic Diverter?

Installing the Amari thermostatic diverter requires precision to ensure lifelong performance and safety. Follow these professional guidelines for a seamless installation:

Step 1: Water Supply Preparation

Before beginning, decide on your hot and cold water sources. Ensure the water lines are thoroughly flushed to remove debris, as foreign particles can damage the sensitive thermostatic diverter cartridge.

Step 2: Positioning the Concealed Body

Place the thermostatic diverter concealed body into the wall recess. It is critical to ensure the body is perpendicular to the base. Use the plastic protective cover to gauge the minimum and maximum depth required for tiling and finishing.

Step 3: Connection and Alignment

Connect the hot and cold inlets to the marked ports on the thermostatic diverter. Ensure the pipes are balanced for optimum results. Most installations require 3/4” BSP (20 mm) lines to maintain the high flow rate Amari is known for.

Step 4: Fitting the Trim and Knobs

Once the masonry work is complete, remove the protective cover. Fit the wall flange and slide the sleeves onto the body. When attaching the temperature handle, align the safety lock precisely at the 38°C mark to calibrate the thermostatic diverter correctly.

Step 5: Testing and Calibration

Turn on the water supply and test all outlets (Shower, Spout, or Body Jets). Rotate the handle to ensure the thermostatic diverter maintains a consistent temperature even when other faucets in the home are turned on.

Maintenance & Performance Tips

Flush Before Use: Always run water through the system before fixing the final trim to avoid clogging the thermostatic diverter filters.

Y-Strainer Installation: Amari recommends installing "Y-Strainers" in the main supply line. This prevents dirt from reaching the thermostatic diverter cartridge, extending its lifespan.

Periodic Cleaning: If you notice a drop in pressure or temperature accuracy, the non-return valves and filters that can be easily accessed and cleaned.

Pressure Compatibility: For the ultimate spa experience with body jets, ensure your water pressure is at a minimum of 3 bar. However, the AL-55-MB thermostatic diverter is engineered to perform reliably even in standard low-pressure environments.

Why Choose Amari Thermostatic Diverter?

Efficiency: With Amari’s thermostatic diverter, you can optimize water usage without compromising on comfort. The efficient design minimizes water wastage by reaching the preset temperature instantly, promoting sustainability while ensuring a luxurious shower experience.

Durability: Crafted from premium high-grade materials, our thermostatic diverter is built to last. Experience long-lasting performance and reliability, backed by our commitment to quality and craftsmanship.

Innovation: Amari is at the forefront of innovation, continually striving to enhance the functionality and design of our products. Our thermostatic diverter exemplifies our commitment to excellence and global design standards.

Maintenance & Cleaning

To maintain the brilliant luster of your PVD finishes (like Brushed Gold or Matt Black), clean only with a soft cloth and mild soap. Avoid abrasive cleaners or acids. For internal maintenance, Amari recommends installing Y-Strainers in the main supply line to prevent silt from reaching the thermostatic diverter filters.

Frequently Asked Questions (FAQs)

What is the advantage of 4 outlets?

It allows you to connect a rain shower, hand shower, body jets, and a spout all to one thermostatic diverter for a full spa experience.

Is PVD better than Chrome?

Yes, Amari’s PVD finishes are highly resistant to scratches and corrosion, offering superior durability compared to standard plating.

Does it work with low water pressure?

Yes, the AL-55-MB is engineered for high-flow performance even on top floors with lower vertical pressure.

What is the warranty on the cartridge?

Amari provides a comprehensive warranty on the thermostatic diverter cartridge, ensuring peace of mind and long-term reliability.
